Digital Sandwich Board

A foldable outdoor advertising display with a rechargeable battery and portable design.

Configuration options

Battery capacity
50 Ah / 80 Ah by screen size
Operating system
Android / Windows
OEM / ODM
Enclosure, branding & hardware

Factory-direct OEM/ODMSample orders from 1 unit 3-year warranty

View terms
View Projects

100% Pre-Shipment Inspection

Burn-in, image quality, touch, ports and appearance. Outdoor units also checked for water and dust protection.

Who it's for

Battery-powered A-boards for restaurant pavements, event entrances, forecourts and pop-up promotions. Choose it when there is no socket and the board must move between positions; rated runtime is 10–12 hours at 1,500 nits, so plan a charge or swap for longer shifts.

Battery-Powered Digital Sign Specifications

YJCEN's outdoor battery-powered digital A-board is available in 32, 43 and 55 inches, with 1500-nit brightness, IP65 protection and a LiFePO4 battery. Each listed size has a rated runtime of 10–12 hours at 1500 nits from a full charge. Battery capacity is 50 Ah for the 32- and 43-inch models and 80 Ah for the 55-inch model.

Scroll horizontally to compare sizes and configurations.

Outdoor Battery-Powered Digital A-Board
Specification32″43″55″
Configuration & dimensions
ModelYJC-320-OP-AYJC-430-OP-AYJC-550-OP-A
Screen size32″43″55″
Screen orientationPortrait
Dimensions (mm)990.8 × 468.2 × 140 mm1236 × 650 × 140 mm1399.6 × 756 × 140 mm
Net weight35 kg50 kg70 kg
Display performance
Native panel resolution1920 × 1080
Active display area (mm)698.4 × 392.85 mm (H×V)940 × 530 mm (H×V)1209.6 × 680 mm (H×V)
Aspect ratio16:9
Brightness1500 cd/m²
Contrast ratio1200:1
Viewing angle178° / 178°
Response time6 ms
Backlight life50,000 hours
System configuration & connectivity
Operating systemAndroid / Windows (selectable)
ProcessorRK3568 / RK3576 (Android); customizable
MemoryCustomizable
StorageCustomizable
ConnectionsUSB × 2, Ethernet RJ45 × 1
NetworkWi-Fi / LAN
Mobile networkOptional 3G/4G
AudioBuilt-in speaker
Configuration options & integration
Battery typeLiFePO4 battery
Rated voltage24 V
Battery capacity50 Ah50 Ah80 Ah
Charging time7 h7 h8 h
Listed Runtime10–12 hours at 1,500 nits, fully charged (rated)
ChargingCharger included
Battery FunctionsLow-battery reminder
StandFoldable carrying stand
PlaybackUSB plug-and-play and automatic loop playback
Power & operating conditions
Ingress protectionIP65
Power supplyAC 100–240 V, 50/60 Hz
Maximum power consumption70 W90 W140 W
Operating environmentOutdoor
Operating temperature−45 °C – 65 °C
Storage temperature−50 °C – 70 °C
Operating humidity10%–80%

Refer to the selected model’s dimension drawing for the complete footprint and mounting details.

Portable Digital Sign Features

This battery-powered digital signage uses a folding A-frame design, also described as a digital A-board or digital sandwich board. It can display promotions or event information where fixed power is inconvenient. Choose the model around the intended operating hours and site conditions, and allow for charging between uses.

Illustration: A wheeled battery-powered advertising display shows a clothing discount beside battery and charging symbols.

Battery Runtime and Charging

The 32-, 43- and 55-inch models are rated for 10–12 hours at 1,500 nits from a full charge. Runtime varies with content and battery condition.

A low-battery reminder and one-button power control support daily use. A charger is included.

Illustration: A battery-powered A-frame display is shown open and folded, with the same shoe discount on both views.

Foldable Stand for Setup and Storage

The foldable carrying stand supports the screen in its display position and reduces the space needed when it is packed away. This is useful for exhibitions, pop-up shops and other settings where the equipment is used for a limited period.

A battery powered display can be positioned beside a product, at an event entrance or near a temporary counter. The placement can follow the purpose of the display rather than a permanent wall installation.

Consider handling requirements when choosing a screen size. The 32, 43 and 55-inch models have net weights of 35, 50 and 70 kg respectively. Check the route between the display position, storage area and charging point, including doorway clearance and any steps.

Illustration: A battery-powered A-frame display shows a burger offer beside a USB drive and rotating cafe campaign thumbnails.

Full HD Screen and USB Playback

The Full HD IPS screen displays photographs, video and short information layouts, with intelligent brightness adjustment. Prepare content for the location and viewing distance.

USB plug-and-play and automatic loop playback let staff prepare a sequence of media files before an event. A battery-powered display screen can show welcome messages, product demonstrations or schedules without needing a networked update process.

Runtime and battery options

Rated runtime: 10–12 hours at 1,500 nits from a full charge. Actual runtime depends on brightness, content and temperature; video at full brightness can be shorter.

Runtime is quoted at a given brightness and content type. The number in a brochure is usually measured at 50% brightness with a static image; video at full brightness can halve it.

Three questions to ask before ordering:

  1. What is the runtime at the brightness I will actually use?
  2. How long does a full charge take, and can the unit run while charging?
  3. Is the battery removable, so a spare can be swapped mid-day?

For a 12-hour pavement shift, plan for a swap battery or a unit with margin. A board that dies at 3 p.m. is worse than a printed one.

This page covers the specification for this model. For the category-level comparison, see the Portable & Battery range.

Weather and theft

  • IP rating — IP54 for covered positions, IP65 for open pavement. Check the battery compartment and the charging port, not just the screen.
  • Wind — a double-sided board is a sail. Use a weighted base or a fixing point; do not rely on the frame alone.
  • Theft — a portable board is easy to carry away. Use a locking base, a chain point, or bring it inside overnight.
  • Heat — a black frame in direct sun gets hot; check the maximum operating temperature and avoid charging in a hot storeroom.
  • Winter — cold reduces lithium capacity by 20–30%; a summer trial does not prove a winter deployment.

Content update options

  • USB — simplest and cheapest; someone walks out with a stick.
  • Wi-Fi — works if the pavement has coverage; test the signal at the board's position.
  • 4G — independent of site Wi-Fi; needs a SIM and a data plan.
  • Cloud CMS — schedule and update across sites.

For a single café, USB is enough. For a chain or a daily-changing menu, 4G plus a CMS pays for itself in staff time.


Black portrait display near a restaurant counter, showing a burger menu with prices and food images.
Europe · Photographed in 2025

Battery-Powered Menu Displays in a European Restaurant

A restaurant in Europe uses YJCEN battery-powered digital signage to display menu items, food images and prices. Placed near the food counter, the portrait screen presents a burger menu and meal information.

All projects

Digital Signs for Events and Pop-Up Shops

At an exhibition booth, the screen can introduce products or show a short demonstration. A pop-up shop can display prices and offers next to a temporary collection. Event teams can use it for welcome messages, schedules and directions.

Choose from 32, 43 and 55-inch screens at 1,500 nits, all with an IP65 rating. For locations that need higher brightness, compare the 43-inch high-brightness outdoor battery display in 2,000 and 2,500-nit versions. Check the battery and runtime specifications for each range separately.

Planning Runtime and Charging Between Events

Select the screen size around the available space and the distance from which people will read it. Then compare the required operating hours with the expected runtime at your chosen brightness. Test representative content and allow time for charging between uses.

Plan charging and storage around the event schedule and the daily operating hours.

Battery-Powered or Mains-Powered Displays

Battery operation is useful when a temporary display position lacks a convenient fixed power supply. If the screen will always operate indoors beside a power outlet, our portable digital signage display offers a mains-powered alternative. Choose the product around how and where it will run.

Manuals and Drawings

Select your screen size and configuration to find the right documents.

43″ · StandardYJC-430-OP-A

Product Manual

Model specifications and configuration details.

Download PDF

Dimension Drawing

Drawing for the selected size and configuration.

Download PDF

Installation Manual

Series installation guide. See the model drawing for dimensions and mounting details.

Download PDF
Browse all product documents

OEM, certification and warranty

YJCEN offers enclosure, colour and private-label customization for integrators and brand owners. Android or Windows configurations, memory and storage can be customized; RK3568 and RK3576 are Android processor options. Your application can be pre-installed and tested on the selected hardware.

Android configurations include a free cloud-based CMS with no limit on the number of accounts.

Samples are available from 1 unit. Standard models typically ship in 3–7 working days and customized units in 15–20 working days. Sample lead time varies by product; the quotation specifies the delivery schedule.

YJCEN's quality management system is ISO 9001 certified. All YJCEN products are CE, RoHS, FCC and ETL certified. CB certification covers our product range.

YJCEN products have a 3-year warranty, excluding user-caused damage and faults caused by improper screen installation.

OEM/ODM options · CB certificate · Warranty terms

MOQ, lead time and what drives cost

MOQ: sample orders from 1 unit; no minimum order quantity for production.

Lead time: standard models typically ship in 3–7 working days after drawing and spec approval. Custom units typically ship in 15–20 working days, plus tooling if a new housing is required.

What drives cost: size, battery, runtime, brightness and enclosure.

What to send:

  • Screen size (32 / 43 / 55 in)
  • Runtime and daily shift length
  • Indoor pavement or outdoor position
  • Quantity and destination country
  • Content update method and branding

Battery-Powered Digital Sign FAQs

How does this differ from the high-brightness battery A-board?

This YJCEN battery A-board offers 1500-nit brightness and IP65 protection in 32, 43 and 55 inches. The high-brightness range is a 43-inch IP65 display with 2000- or 2500-nit configurations. Each range has its own battery capacity and runtime specifications.

Compare the high-brightness battery A-board

Can the display run without a mains connection?

Yes. The built-in battery powers the screen during use. It needs to be charged from a suitable power source between operating periods.

How long does the battery last?

The rated runtime is 10–12 hours at 1,500 nits from a full charge for each listed size. Allow time to recharge between operating periods.

Can staff update it with a USB drive?

Yes. USB plug-and-play and automatic loop playback support a locally prepared collection of media files.

Can the same content be reused at several events?

Yes. Prepare the files for the selected panel and update dates, prices and venue information as needed. Test the loop on the display so that each message stays on screen long enough to read.

Is it suitable for rain or direct outdoor exposure?

The 32, 43 and 55-inch models listed here have an IP65 protection rating and are specified for outdoor use. Check the installation conditions and follow the selected model’s operating and charging instructions.

How long does the battery last in winter?

Expect 20–30% less runtime in cold weather. If the board runs a full shift in summer with little margin, specify a larger battery or a swap pack for winter.

Can it be left outside overnight?

Yes, with an IP65 unit and a secure fixing. For theft-prone locations, bring it inside or use a locking base.

What is the difference between a digital sandwich board and a digital A-frame?

Mostly the frame: a sandwich board hinges and folds, an A-frame is a rigid double-sided frame. Both are double-sided pavement units; the choice is about handling and storage.

Discuss Your Project

For a project quotation, share the quantity, installation country and daily operating hours. A photo of the display position will help us discuss screen size, placement and charging arrangements. Contact YJCEN.
